Technical Specifications DRIVE MOTOR Avinox M1 2025, 250W (MAX 1000W) 105 Nm (120 Nm in Boost mode) BATTERY Avinox / 800 Wh (22.28 Ah) CHARGER 12 A (included) RANGE up to 157 km DISPLAY Avinox DP100, 2" OLED touchscreen CONTROL Avinox Wireless Controller, left and right USB CONNECTION USB Micro-C WALK ASSIST yes CONTROL UNIT Integrated into the motor PEDAL TORQUE SENSOR Torsion-based FRAME FRAME Alu 6061 - Frame size XL FORK FOX AWL HD 36 Air 29" BOOST, 160 mm travel, 44 mm offset SHOCK FOX Float Rhythm, 2pos, Evol LV, 210x55 WHEELS WHEEL SIZE (INCH) 29" WHEELS CRUSSIS 29" disc, double-walled, lined, 30 mm FRONT BRAKES SRAM DB8 Stealth, hydraulic, Rotor 200 mm REAR BRAKES SRAM DB8 Stealth, hydraulic, Rotor 200 mm FRONT HUB CRUSSIS disc, industrial bearings, 32D, BOOST axle 15x110 mm REAR HUB CRUSSIS disc, industrial bearings, 32D, BOOST axle 12x148 mm FRONT TIRE MAXXIS ASSEGAI 29x2.50 REAR TIRE MAXXIS MINION DHR II 29x2.50 LOAD CAPACITY WEIGHT There is no fixed standard for weighing electric bikes that all manufacturers adhere to. Some brands provide artificially reduced weights. To determine the weight of a bike, you should weigh it directly in the shop. MAXIMUM TOTAL WEIGHT / MAX LOAD 120 kg COMPONENTS HANDLEBAR CRUSSIS AL Ø 31.8 mm, Width 780 mm STEM CRUSSIS AL 45 mm, Angle 0°, Ø 31.8 mm GRIPS CRUSSIS, with sleeve, Ø 33 mm, black HEADSET ACROS TAPERED 1 1/8" - 1.5", ICR SEAT SELLE ROYAL SEAT CLAMP CRUSSIS AL, Black 34.9 mm SEAT POST X-FUSION MANIC 30.9 Ø, telescopic, Travel S - 125 mm, M - 150 mm, L - 170 mm, XL - 190 mm TRANSMISSION GEARS 1 x 12 REAR DERAILLEUR SRAM 70 T-Type Eagle, 12 speeds SHIFTER SRAM 70 T-Type Eagle, MMX CHAIN SRAM 70 T-Type, 12 speeds CASSETTE SRAM CS-PG1270 T-Type Eagle, 11-52z CRANKSET SRAM T-Type Eagle 34Z, DJI Avinox ISIS 155 mm
