Technical Specifications DRIVE MOTOR Avinox M1 2025, 250W (MAX 1000W) 105 Nm (120 Nm in Boost mode) BATTERY Avinox / 800 Wh (22.28 Ah) CHARGER 12 A (included) RANGE up to 157 km DISPLAY Avinox DP100, 2" OLED touchscreen CONTROL Avinox Wireless Controller, left and right USB CONNECTION USB Micro-C WALK ASSIST yes CONTROL UNIT Integrated in the motor TORQUE SENSOR Torsion-based FRAME FRAME Aluminum 6061, frame size XL FORK FOX AWL HD 36 Air 29" BOOST, 160 mm travel, 44 mm offset SHOCK FOX Float Rhythm, 2-position, Evol LV, 210x55 WHEELS WHEEL SIZE (INCH) 29" WHEELS CRUSSIS 29" disc, double-walled, reinforced, 30 mm FRONT BRAKES SRAM DB8 Stealth, hydraulic, rotor 200 mm REAR BRAKES SRAM DB8 Stealth, hydraulic, rotor 200 mm FRONT HUB CRUSSIS disc, industrial bearings, 32D, BOOST thru-axle 15x110 mm REAR HUB CRUSSIS disc, industrial bearings, 32D, BOOST thru-axle 12x148 mm FRONT TIRE MAXXIS ASSEGAI 29x2.50 REAR TIRE MAXXIS MINION DHR II 29x2.50 LOAD CAPACITY WEIGHT There are no fixed standards for weighing electric bicycles that all manufacturers adhere to. Some brands list artificially reduced weights. To determine the weight of a bicycle, it must be weighed directly in-store. MAXIMUM TOTAL WEIGHT / MAX. LOAD 120 kg COMPONENTS HANDLEBAR CRUSSIS AL Ø 31.8 mm, width 780 mm STEM CRUSSIS AL 45 mm, angle 0°, Ø 31.8 mm GRIPS CRUSSIS, with sleeve, Ø 33 mm, black HEADSET ACROS TAPERED 1 1/8" - 1.5", ICR SADDLE SELLE ROYAL SEAT CLAMP CRUSSIS AL, Black 34.9 mm SEAT POST X-FUSION MANIC 30.9 Ø, telescopic, travel S - 125 mm, M - 150 mm, L - 170 mm, XL - 190 mm GEARING GEARS 1 x 12 REAR DERAILLEUR SRAM 70 T-Type Eagle, 12-speed SHIFTER SRAM 70 T-Type Eagle, MMX CHAIN SRAM 70 T-Type, 12-speed CASSETTE SRAM CS-PG1270 T-Type Eagle, 11-52z CRANKSET SRAM T-Type Eagle 34Z, DJI Avinox ISIS 155 mm
