Frame
Frame
Sunday 29, aluminum 6061 T4-T6, hydroformed tubes with variable thickness, tapered 1”1-8-1”1-2 head tube, Hidden Power reverse technology
Suspension
Fork
Sunday 29, full carbon, tapered 1”1-8-1”1-2 steerer, FlatMount 180 mm direct brake mount, 12x100mm axle, 50 mm offset, for 700x50 tires (max 700x42 with fenders), fender and luggage rack mounts
Motor System
Motor
Bosch, Performance Line, 250W, 65Nm
Battery
Bosch, PowerPack 500Wh
Range*
117 km
Conditions
Maximum, calculated for a person weighing 70kg under ideal usage conditions
Charger
Bosch, 4Ah
Display
Bosch, Purion - "Walk assist"; Eco, Tour, Sport, Turbo
Transmission
Rear Derailleur
Shimano, Deore, RD-M5120-SGS, 10-11 speeds
Chainring
42 teeth, Narrow Wide, chainring guard
Cassette
Sunrace, CSMS7, 11 speeds, 11-42
Chain
Sram, PC1110, 11 speeds, 118 links
Shifter
Shimano, Deore, SL-M5100-R, 11 speeds
Crankset
Moustache, aluminum, 170mm
Brakes
Front Brake
Alhonga, HJ-472, hydraulic disc
Rear Brake
Alhonga, HJ-472, hydraulic disc
Front Disc
Alhonga, 160mm
Rear Disc
Alhonga, 160mm
Wheels
Hubs
Front: Moustache, 24 holes, 12x100, thru axle — Rear: Moustache, 24 holes, 12x142, thru axle
Rims
Moustache, al:30, aluminum 6061, welded, 24 holes, 700c, internal width 22mm
Tires
Maxxis, Rambler, 700x50C, 120TPI
Cockpit
Saddle
Selle Royal, VIVO
Seat Post
EXA, 860i, telescoping suspended with handlebar control, 31.6mm
Seat Post Travel
75mm
Seat Clamp
Moustache, aluminum, 34.9mm
Handlebar
Moustache Flexbar by Baramind, 660mm, dampens vibrations, S-M: Medium, L-XL: Hard
Stem
Moustache, forged aluminum 3D, 8
