26"
9 SPEED
Weight only 11.2 kg
12mm thru-axle rear
Thoughtful geometry
Low bottom bracket
Deep-drawn chainstay for less chain slap on the stay
For children around 9 years old or around 130cm tall
EQUIPMENT
Frame: Lightweight & high-quality 6061 Aluminum, 12mm thru-axle, Tapered Headset
Fork: RST First Air suspension fork, 80mm, Lockout/Rebound
Stem: 3D forged 6061T6 Aluminum, 31.8mm clamp, Length 40mm, Angle +7°
Handlebar: Lightweight 7050 Double-Butted Aluminum, 31.8mm clamp, 12mm Rise, Width 640mm, Backsweep 9°
Grips: Lightweight screw-on grips with Kraton grip surface
Crank: SUNRACE Aluminum crank, 160mm length, 30T Narrow Wide chainring
Derailleur: Shimano Altus Rapidfire Plus 1x9 shifter
Rear Derailleur: Shimano Alivio
Cassette: Shimano HG-400 11-36, 9-speed
Pedals: VP-225
Brakes: Shimano MT-200 brakes (front 180mm/rear 160mm)
Rims: NEWMEN X.A.25 rims
Hubs: Aluminum hubs with sealed industrial bearings
Tires: Schwalbe Tough Tom, 26 x 2.25
Tubes: Kenda Super-Light with Presta valve
Saddle: Age-appropriate ergonomics, durable cover material, free of plasticizers and pollutants
Seatpost: Aluminum seatpost, diameter 31.6mm, length 300mm
SIZE CHART 26" MTB
Min. inseam length: 57 cm
Age
around 9
Height
around 130 cm
The most important and accurate criterion for choosing the right frame size is the inseam length. Age and height provide only a very rough guideline.
Please measure the inseam length with shoes on, as shoes are also worn when cycling.
