Technical Specifications DRIVE MOTOR Avinox M1 2025, 250W (MAX 1000W) 105 Nm (120 Nm in Boost mode) BATTERY Avinox / 800 Wh (22.28 Ah) CHARGER 12 A (included) RANGE up to 157 km DISPLAY Avinox DP100, 2" OLED touchscreen CONTROL Avinox Wireless Controller, left and right USB CONNECTION USB Micro-C WALK ASSIST yes CONTROLLER Integrated into the motor TORQUE SENSOR Torsion-based FRAME FRAME Carbon, frame size XL FORK FOX Podium, Grip X2, Kashima, 29" BOOST, 160 mm travel, 44 mm offset SHOCK FOX Float X Live Valve Neo, Evol LV, 210x55 WHEELS WHEEL SIZE (INCH) 29" FRONT BRAKES SRAM Maven Ultimate, hydraulic, 200 mm rotor REAR BRAKES SRAM Maven Ultimate, hydraulic, 200 mm rotor FRONT WHEEL FSA Gradient i30 Carbon 29" - 20/110 mm REAR WHEEL FSA Gradient i30 Carbon 29" - 12/148 mm, SRAM XD FRONT TIRE MAXXIS ASSEGAI 29x2.50 REAR TIRE MAXXIS MINION DHR II 29x2.50 COMPONENTS HANDLEBAR RACEFACE Turbine AL 35 mm, width 780 mm, rise 40 mm STEM RACEFACE Turbine AL 40 mm, angle 0° GRIPS RACEFACE Getta, 30 and 33 mm, black HEADSET FSA NO.57-HBS/U-200 Block headset 1 1/8" - 1.5" SEAT Fizik Terra Ridon X5 - 145 mm SEAT CLAMP CRUSSIS AL, black 34.9 mm SEATPOST FOX Transfer Neo 30.9 mm diameter, telescopic, travel M - 150 mm, L - 175 mm, XL - 200 mm DRIVETRAIN GEARS 1 x 12 DERAILLEUR SRAM XX Eagle AXS T-Type, 12-speed SHIFTER SRAM AXS Rocker Controller Right, MMX CHAIN SRAM XX Eagle T-Type Flattop 126 links, 12-speed CASSETTE SRAM XS-1297 Eagle T-Type 10-52T CRANKSET SRAM T-Type Eagle 34T, SRAM XX ISIS 165 mm
